Vertical Series

Our exposed fastener metal panels offer an ideal roof and/or wall application for commercial, industrial, and architectural buildings.

Features & Benefits

24 & 22 Tru-Gauge™ and .032″ Aluminum
Custom 20 & 18 Tru-Gauge™ and .040″ Aluminum (please inquire)
1:12 minimum pitch if seam height < 1″ recommended when installed with butyl sealant
3:12 minimum pitch if seam height is ≥ 1″ recommended when installed with butyl sealant
Custom lengths 2′ to 20′ 10″
Standard trim, custom trim and accessory packages available
Color matched neoprene washered screws
Roof and vertical or horizontal wall application
Manufactured in Salem OR, Riverside CA, and Sacramento CA
OverEZee™ Retro-fit systems available

24 & 22 Tru-Gauge™ Kynar 500® Painted Steel
.032″ Kynar 500® Painted Aluminum
24 Tru-Gauge™ G-90 Galvanized or AZ-50
24 & 22 Tru-Gauge™ bare Zincalume® Plus AZ-55 Per ASTM A-792 (no finish warranty – 25 year perforation warranty)
.040″ Kynar 500® Painted Aluminum (inquire)
24 Tru-Gauge™ Bonderized
22 gauge Rusteel Plus™ (A606)
Custom 20 & 18 Tru-Gauge™ and .050″ and .063″ Aluminum (please inquire)
16 OZ & 20 OZ Real Copper
Kynar 500® and substrate testing data available

*TMP .625-4.5-36 siding only coming 2024. All other profile testing coming in 2023.

21 Standard Kynar® Colors, 5 Metallic Colors and 3 Specialized Colors
Vintage® has a color range that can vary from batch-to-batch and have directional variations
- For more information: click here
Rusteel Plus™ has no metallic coating, is unpainted and has no warranty
- For more information: click here
Kynar 500® Paint System – the ultimate in exterior durability and color retention
“Cool” color pigments are specially designed to reflect infrared light, reducing heat gain to dwelling, and conform with ENERGY STAR® criteria
Superior quality, two-coat, 70% resin finish, applied at a 1 mil. thickness
20 and 30 year commercial paint warranty: Contact TMP for warranty specifications
21 Standared ArmorTech™ Colors, Zincalume® Plus and Galvanized
ArmorTech™ Paint System – excellent exterior durability
40-year residential paint warranty
